Advanced Hydraulic Digital Flow Meter: Ensuring Precision in Fluid Power Applications

Model: HFM-400-1

This innovative Hydraulic Digital Flow Meter is designed to meet the rigorous standards outlined in ISO/OECD 789-10:2006, empowering engineers and technicians with highly accurate and reliable flow measurement capabilities for diverse fluid power applications. Featuring a robust design, advanced sensors, and user-friendly operation, this instrument delivers exceptional performance for precise system analysis and optimization.

Unparalleled Measurement Accuracy:

Flow Range: 10-400 l/min with ±1% accuracy across the entire range ensures precise flow rate determination.

Maximum Pressure: Handles pressures up to 420 bar with a pressure gauge accuracy of ±1.6%, ideal for high-pressure systems.

Temperature Measurement: Measures temperature within a range of 0-120°C with a thermistor sensor boasting ±1°C (2°F) accuracy.

Tachometer Functionality: The integrated tachometer measures hydraulic motor shaft rotation speed within a 300-6000 rpm range with ±1.4% accuracy, providing valuable insights into system dynamics.

Enhanced Functionality and Safety:

Built-in Loading Valve: Offers smooth and controlled pressure increase in either flow direction, facilitating system setup and adjustments.

Pressure Relief System: Integrated safety fuses divert excess working fluid into an internal bypass channel in case of pressure exceeding the maximum limit, safeguarding the system from potential damage.

Guaranteed Traceability:

All measuring devices within this system are accompanied by valid calibration certificates issued by a metrological service accredited according to ISO/IEC 17025:2017. These certificates detail measurement uncertainty and reference information, ensuring data reliability and compliance with industry standards. The calibration certificates remain valid for one year from the date of commissioning.

The Hydraulic Digital Flow Meter is an invaluable tool for engineers, technicians, and professionals working in the field of fluid power. Its exceptional measurement accuracy, comprehensive functionality, and safety features make it ideal for a wide range of applications. This advanced flow meter empowers users to gain deeper insights into system performance, optimize operations, and ensure the efficient and reliable operation of fluid power systems. Contact with us for further information.
